Wheel 17,5х6,75 К

RZB14018OE

Tubless wheels with 15° bead seats for trucks, buses, semi-trailers, trailers

Wheels Size 17.5 х 6.75

Drawing No. RZB14018OE

SAP code RZB14018OE

Applicability semi-trailers

Send request

*Actual product may differ from image shown

Wheel characteristics

Production Zainsk

Wheels Size (E&F) 17.5 х 6.75

Bolt Hole No. 10

Bolt Circle, mm (A) 225

Center hole diameter, mm (B) 176

EUWA М22

Bolt holes diameter, mm (D) 26

HMA, mm (G1) 140

ET, mm (G2) 129.5

Max. load (kg) 3150

Disc thickness, mm (C) 10.5

Wheel material steel

Drawing No. RZB14018OE

Applicability semi-trailers

Packing PCs 20

Alignment type CH

Wheel weight, kg 24.9

Valve V3.20.4

Permissable tire sizes 215/75R17,5

Version silver RZB14018OE-HB0A200

Dimensions (w*l*h, mm) 445*445*172
